Nitrogen generation systems protect steel pipes in dry and pre-action sprinkler systems from corrosion. The concepts behind corrosion and MIC are explained in this blog:Understanding Corrosion and Microbiologically Induced Corrosion (MIC) Both wet and dry (pre-action) sprinkler systems have corrosion issues, but they are dramatically worse in pre-action and dry pipe sprinkler systems.
New and existing sprinkler systems can benefit by the application of a nitrogen generation system. For new sprinkler installations, application of nitrogen can dramatically improve the lifespan of the system. For existing installations where corrosion has already started, the piping can be preserved by using nitrogen instead of compressed air. Nitrogen can add considerable useful life to the sprinkler system.
Nitrogen generation systems:
Pre-Engineered Plug and Play Systems
Up to 950 gallons total sprinkler system capacity
Integral oil-less air compressor
Air bypass alarm included
ORR Protection offers many solutions for combating corrosion in sprinkler systems including diagnosis and prevention options. We also install and service nitrogen generator systems. Know for sure if your system is at risk. We will ensure your all your fire protection systems are ready to perform when called upon. Click here to schedule an appointment today.
Nitrogen Generator Specifications
|Total System Capacity||950 gal||1,850 gal||3,200 gal||3,200 gal||10,000 gal||18,500 gal||22,500 gal|
|Single System Capacity (1)||265 gal||345 gal||950 gal||variable||1,440 gal||2,025 gal||2,900 gal|
|Size (H x W x D)||36 x 24 x 8||58 x 32 x 40||58 x 32 x 40||52 x 24 x 40||78 x 24 x 12 (2)||78 x 24 x 12 (2)||78 x 24 x 12 (2)|
|Weight||125 lbs||400 lbs||425 lbs||152 lbs (2)||264 lbs (2)||300 lbs (2)||300 lbs (2)|
|Configuration||Wall Mount||Skid mount||Skid mount||Stand alone||Stand alone||Stand alone||Stand alone|
|Electrical||120V||120V||120V/460V/3p (3)||120V (4)||120V (4)||120V (4)||120V (4)|
|Air Compressor||Integral oil-less||Integral oil-less||Integral oil-less||Oil-less/house air (5)||Oil lubricated||Oil lubricated||Oil lubricated|
|Lead Time (6)||72 hrs||72 hrs||72 hrs||72 hrs||72 hrs||72 hrs||72 hrs|
|Warranty (7)||1 year||1 year||1 year||1 year||1 year||1 year||1 year|
Venting and Pressure Control Devices
